Product introduction
Closed cell EVA single-sided foam tape is easy to cut and joint for a good style in air handling and acoustic engineering, building and construction, automotive, electrical and electronic, furniture and glass, printing, packaging, advertisement and many other industries. It's closed cell foam with excellent holding power, peel strength and initial adhesion
| Specification Sheet for：EV90 | |||||
| Material Properties | Unit | Test Method | Measured value | ||
| Density | Kg/m3 | ASTM D1667 | 90±10 | ||
| Hardness |  | ASTM D2240 | 23-29 | ||
| Tensile Strength | KPa | ASTM D638-03 | 1100 | ||
| Elongation at break | % | ASTM D638-03 | 210 | ||
| Compressive strength | KPa | ASTM D1667-05 | 49 | ||
| Tear strength | N/cm | ASTM D1004-09 | 3.2 | ||
| Compression set | % | ASTM D395-03 | 3.5 | ||
| Operating temperature | ℃ | --- | -40 to +80 | ||
| Flammability | --- | UL94-2013 | UL94 HF-1 | ||
| --- | FMVSS 302 | Pass | |||
